Streamax DP7S
Back to Products
Streamax
Streamax DP7S
7-inch HD in-cab monitor for commercial vehicles. Shows live feeds from up to four connected cameras - one SD or AHD camera per input - at 1024×600 with per-channel mirror and flip, so reversing and side views appear the right way round. Accepts a wide 9-36V DC supply for cars, trucks, and buses and adjusts the backlight automatically to ambient light. Five alarm inputs and an RS232 port tie the screen into vehicle signals and a host MDVR. Built for the cab, it runs from -30°C to +70°C and withstands 2.17G vibration and 80G impact behind an IP30 housing on a mounting bracket.
Interested in this product?
Get in TouchKey Features
- 7-inch HD display, 1024×600, up to 1000 cd/m² with automatic backlight
- Four video inputs - one SD or AHD camera per channel, up to 1080P
- Per-channel mirror and flip for correct reversing and side-view orientation
- Wide 9-36V DC input for cars, trucks, and buses
- Five alarm inputs and RS232 for MDVR and vehicle-signal integration
- Rugged in-cab build: -30°C to +70°C, 2.17G vibration, 80G impact, IP30
Camera System
Camera ArchitectureSelf-Contained
AI ProcessingNone
Standalone CapabilityNone
DeploymentIndoor
Expansion & Connectivity
Interfaces
AHDCVBSRS232
Physical Specifications
Operating Temp.-30°C to +70°CIP RatingIP30
Quick Info
- Brand
- Streamax
- Model
- DP7S
- Interface
- AHD, CVBS, RS-232
- Architecture
- Self-Contained
- Operating Temperature
- -30°C to +70°C
