Promag MR2S

The MR2S is a compact 13.56MHz Mifare UID Reader with 1-Wire and RS232 interface, designed to integrate with vehicle trackers and controllers. With 10-48VDC power input, it can be installed in any vehicle. It serves as a cost-effective alternative to iButton, enabling fleet management solutions with low-cost Mifare cards. Weather resistant and mountable on metal surfaces.

Interested in this product?

Get in Touch

Key Features

13.56MHz frequency for reading Mifare RFID cards
Read UID of ISO 14443A Mifare, DESFire, and Ultralight cards
Dual interface: 1-Wire and RS232 output (default: 1-Wire)
Supports daisy-chain via 1-Wire input interface
Wide power range: 10-48 VDC for any vehicle type
Alternative to iButton — use low-cost Mifare cards instead
Weather resistant for harsh vehicle environments
Metal surface mountable
LED and buzzer indicators for read status

Ports & Interfaces

1-Wire1-Wire

×1

Bidirectional

1-Wire data output (default interface)

RS-232RS232

×1

Bidirectional

RS232 TX/RX (configurable via software)

Physical Specifications

Weight85 g

Interested in this product?

Contact our sales team for more information.

Get in Touch

Quick Info

Brand: GigaTMS
Model: MR2S
Interface: 1-Wire, RS-232

Downloads & Resources

Promag MR2S Datasheet
