Technoton GNOM DDE

Pressure sensor for use in pneumatic suspension systems of vehicles, obtaining pressure information from pneumocylinders or the pneumatic network to derive axle load. Produces a stabilized analog output voltage from 0.25 V to 3.80 V proportional to input pressure (0-0.8 MPa), independent of on-board circuit voltage.

Interested in this product?

Get in Touch

Key Features

Pressure sensor for pneumatic / air-suspension vehicle systems
Pressure measurement range 0-0.8 MPa
Stabilized analog output 0.25-3.80 V independent of on-board voltage
Wide supply voltage range 8-32 V (24 V nominal)
M16×1.5 connection thread (M22×1.5 with adapter from MK DDE #1 kit)
Operating temperature -40 to +80 °C, IP55 enclosure
Service life 5 years; 24-month warranty

Approvals & Certifications

ISO 9001:2015

Physical Specifications

Operating Temp.-40 to +80 °CIP RatingIP55

Interested in this product?

Contact our sales team for more information.

Get in Touch

Quick Info

Brand: Technoton
Model: GNOM DDE
Sensor Type: Weight Sensor
Interface: Analog, CAN
IP Rating: IP55
Operating Temperature: -40 to +80 °C

Downloads & Resources

GNOM DDE Specification GNOM DDE Operation Manual
