Eurosens DDS BT

Name: Eurosens DDS BT
Brand: Eurosens

BLE Axle Load Sensor for Spring Suspension Vehicles with 5-Year Battery

Back to Products

Eurosens

Eurosens DDS BT

IoT Enabled

Wireless axle load sensor for vehicles with spring suspension. Mounts on the chassis with a vertical rod connecting to the bridge. Suspension deflection under load converts to rod displacement and lever rotation, producing a BLE output signal proportional to axle load. 5-year battery life.

Interested in this product?

Get in Touch

Key Features

Wireless Bluetooth Low Energy (BLE) transmission
Compatible with monitoring terminals (Teltonika, Galileosky, Navtelecom)
Built-in battery with 5-year lifespan
No wiring required for installation
200-meter radio range in line of sight
IP67 protection for harsh operating conditions

Connectivity

Bluetooth

Physical Specifications

Operating Temp.-40 to +85°CIP RatingIP67

Interested in this product?

Contact our sales team for more information.

Get in Touch

Quick Info

Brand: Eurosens
Model: DDS BT
Sensor Type: Weight Sensor
Interface: BLE
IP Rating: IP67
Operating Temperature: -40 to +85°C

Downloads & Resources

DDS BT Datasheet DDS BT Operating Manual
