Technoton GNOM DP

Technoton

Technoton GNOM DP

Axle load (shift) sensor for measuring axle load and cargo mass on vehicles with leaf-spring suspension. Produces a stabilized analog output voltage proportional to the axle suspension lever angle, independent of on-board circuit voltage. A CAN variant (GNOM DP CAN, S6/CAN 2.0B SAE J1939) is also available.

Interested in this product?

Get in Touch

Key Features

Measures axle load and cargo mass on leaf-spring-suspension vehicles
Stabilized analog output independent of on-board network voltage
Output voltage range 1.54-3.46 V across -40° to +40° lever angle
CAN variant: S6 / CAN 2.0B SAE J1939
Wide supply voltage range 8-32 V (24 V nominal)
Operating temperature -40 to +80 °C, IP55 enclosure
E-mark (E28) type approved
Service life 5 years; 24-month warranty

Approvals & Certifications

E-mark (E28)ISO 9001:2015

Physical Specifications

Operating Temp.-40 to +80 °CIP RatingIP55

Interested in this product?

Contact our sales team for more information.

Get in Touch

Quick Info

Brand: Technoton
Model: GNOM DP
Sensor Type: Weight Sensor
Interface: Analog, CAN
IP Rating: IP55
Operating Temperature: -40 to +80 °C

Downloads & Resources

GNOM DP Specification GNOM DP CAN Specification GNOM DP Operation Manual
