Streamax Z5

Back to Products
Streamax Z5 Transparent Cargo Box AI camera
Streamax

Streamax Z5

The Z5 Transparent Cargo Box is a self-contained AI camera for real-time cargo volume monitoring in trailers and containers. A dual-camera setup pairs a 4K black-light interior lens with a 1080P exterior lens, while on-device AI deep-learning algorithms perceive load volume and loading rate without a separate recorder or host. It runs on its own multi-carrier 4G, GPS, Wi-Fi, and Bluetooth, with an external solar panel and 10.4Ah battery for untethered operation up to 90 days in power-saving mode. A 1-Wire bus integrates trailer and container sensors, and the IP69K aluminium housing withstands washdown and -40°C to +70°C operation.

Interested in this product?

Get in Touch

Key Features

  • Dual camera - 4K black-light interior lens plus 1080P exterior lens
  • On-device AI perception of cargo volume and loading rate
  • Self-contained operation with no host MDVR or external recorder required
  • Multi-carrier 4G LTE, GPS, Wi-Fi, and Bluetooth 5.1 connectivity
  • External solar panel and 10.4Ah/76Wh battery for untethered operation up to 90 days in power-saving mode
  • 1-Wire bus for trailer and container sensor integration
  • Bluetooth, RS232, and CAN bus support for additional peripherals
  • 6-axis accelerometer for motion and event detection
  • microSD recording with H.264/H.265 compression (256GB card included)
  • Magnetic door sensor included for cargo-access monitoring
  • IP69K aluminium-alloy housing rated -40°C to +70°C

AI Capabilities

Specialized AI

Cargo Monitoring

Camera System

Camera ArchitectureSelf-Contained
AI ProcessingOn-Device
Standalone CapabilityFull
Facing
Cargo
Lens Count2
DeploymentIndoor/Outdoor
IR Night VisionSupported

Expansion & Connectivity

2
I/O Inputs
2
I/O Outputs
1
RS232 Ports
Cellular4g
WiFi
Bluetooth

GNSS

GPS

Connectivity

CellularWiFiBluetooth

Interfaces

RS2321-WIRECAN

Ports & Interfaces

RS-232
×1
Bidirectional
GPIO
×2
Input
GPIO
×2
Output
1-Wire
×1
Bidirectional
CAN Bus
×1
Bidirectional
Cellular
×1
Bidirectional
Wi-Fi
×1
Bidirectional
Bluetooth LE
×1
Bidirectional

Physical Specifications

Operating Temp.-40°C to +70°CIP RatingIP69K
